Dual-Sheave Stringing Block With Synchronized Rotation
1. Dual-Sheave Performance
- •
Simultaneous operation of two sheaves for balanced load distribution
- •
Supports cable diameters up to 80mm
- •
Working load limit: 15,000 lbs (6,804 kg)
2. Industrial-Grade Construction
3. Advanced Load Management
- •
Automatic load balancing between sheaves
- •
Individual sheave brake systems
- •
Real-time load monitoring
4. Ergonomic Design
- •
30% lighter than comparable steel blocks
- •
Centralized control panel
- •
Quick-release sheave access
5. Comprehensive Applications
- •
Ideal for:
- •
Bundle conductor installation
- •
Heavy transmission line work
- •
Long-span cable installations
- •
High tension stringing
- •
Special cable configurations
6. Low Maintenance Operation
- •
Self-lubricating bearing system
- •
Corrosion-resistant materials
- •
Field-serviceable components
7. Productivity Features
- •
40% faster than single sheave blocks
- •
Reduces cable wear by 60%
- •
Enables precise tension control
8. Job Site Ready
- •
Includes mounting hardware kit
- •
Protective transport case
- •
Pre-assembled for immediate use
9. Professional Certifications
- •
ASTM F2434 compliant
- •
CE certified
- •
IEEE 524 rated
10. Long-Term Value
11. Size Options
- •
Sheave diameters: 400mm, 500mm, 600mm
- •
Groove configurations: matched pairs
- •
Custom sizes available
12. Environmental Resistance
13. User Features
14. Package Contents
- •
Tandem sheave main unit
- •
Spare bearing set
- •
Mounting hardware kit
- •
Operation manual
15. Industry Applications
- •
Extra high voltage transmission
- •
Renewable energy interconnects
- •
Bridge cable installations
- •
Industrial power projects
- •
Utility maintenance programs
16. Performance Benefits
17. Technical Innovations
18. Purchase Options
- •
Direct from manufacturer
- •
Volume discounts
- •
Global availability
19. Training Support
- •
Installation videos
- •
Safety training modules
- •
Maintenance tutorials
20. Quality Assurance
| Item number | Model | Applicable Conductor | Rated load (kN) | Weight (kg) | Remark |
| 10211 | SHR-2.5 | LGJ300-500 | 25 | 11 | Aluminium sheave |
|
| 10212 | SHRN-2.5 | LGJ300-500 | 25 | 9.5 | Nylon sheave |
|
